Precision Gears Lite [ Addon ]

£0+
26 ratings

TLDR read the bold text.

This is the Free feature reduced version of Precision Gears a blender addon developed to bring an array of mathematically accurate involute gears to the precision world of Blender. Not only that, it's all incapsulated inside the closest thing to a faux "parametric" system, giving you the ability to change your gears on the fly.

Minimum version: Blender 2.92

- PLEASE NOTE -

This is a "beta" release some pretty big & exciting changes will be coming to the paid addon in the next coming months. Plus a whole bunch of videos and a wiki eventually. For the time being, if you find any consistent bugs that you are able to replicate or have any future development ideas I would love to hear from you. The best place is in the maker tales discord in the Precision Gears channel link: HERE. Alternatively, you can fill in this form: Here not reviewed as often.

I'm currently developing the gear "presets" if you have any ideas of how I should standardize these I would love to know your thoughts.


To get all the features that are listed below head on other to the full version of the addon linked: HERE.


Gears & Features currently available:
Those marked with a (*) are included in this lite version.

Gears

  • Spur Gear *
  • Helical Gear
  • Herringbone Gear
  • Rack Gear
  • Internal Gear
  • Internal Herringbone Gear
  • Internal Helical Gear
  • Bevel Gear
  • Spiral Bevel Gear
  • Worm Gear


Features

  • Center Extrusions
  • Set Screws
  • Cross Bore *
  • Round Subtract Bore (Set Screw) *
  • Round Additice Bore (Key) *
  • Polygon Bore ( Triangel / Hex ect.) *
  • Bore Previews *
  • Preset Creation
  • Global Scaling *


Soon to come:

  • Gears to keep material assignments when changing parameters *
  • Internal gears outside perimeters perfectly round
  • Cross bore. XY parameters should be the total length of bore extrusion *
  • Gear face chamfering/bevelling from tip (Spur, Internal, Helical, Herringbone, Rack)
  • Tooth crowning (Spur, Internal)
  • Tooth flank tip relief (Spur, Internal, Helical, Herringbone, Rack)
  • Tooth undercut (Spur, Helical, Herringbone)
  • Rounded tooth tips/reliefs (Spur, Internal, Helical, Herringbone, Rack)
  • Tooth flank base relief (Rack)
£
